Tone Master® Pro, EU

24,000,000.00 UZS

Tone Master Pro is the first no-compromise multi-effects guitar workstation that features the amazing sound quality that the Tone Master series is known for. Combining a powerfully intuitive interface and the most comprehensive I/O array available, the Tone Master Pro is the best sounding, most powerful and easiest to use guitar processor ever.

    Reserve and Collect

    SKU: 2274906000 Category:

    Tone Master Pro is the first no-compromise multi-effects guitar workstation that features the amazing sound quality that the Tone Master series is known for. Combining a powerfully intuitive interface and the most comprehensive I/O array available, the Tone Master Pro is the best sounding, most powerful and easiest to use guitar processor ever.

    Tone Master Pro features over 100 of the world’s most popular amps and effects, including all of the classic Tone Master Fender models, the first officially licensed EVH 5150 III Stealth model, and other can’t live without classics that have all been perfectly replicated using our proprietary Tone Master Modeling process. Tone Master Pro’s lightweight, rugged, stage-friendly form factor is as beautiful as it is functional. With a full-color touchscreen, stunning graphics, and intuitive user interface, dialing in the perfect tone has never been easier or more inspired.

    Create Presets, customize your footswitch assignments and combine them to create Songs and organize into Setlists with ease. Tone Master Pro’s 10 custom-designed footswitch encoders make editing a breeze, giving you instant access to all your presets and parameters and make adjustments just like you would on the real thing. Connect to our Tone Master Pro Control app via USB for creating, editing and sharing your own presets or for auditioning and downloading thousands of tones created by Fender’s community of players and artists.


    Features

    • Over 100 Tone Master quality Amp & Effect Models
    • Over 6000 Fender-captured Impulse Responses with a variety of cabinet and microphone options
    • 3rd Party IR support
    • 7 inch Color Touch-screen
    • Innovative Song & Setlist modes
    • 60 second Stereo Looper
    • 4 Effects Loops for integrating your favorite pedals
    • Instrument and XLR mic inputs
    • 10 proprietary footswitch/encoders with LCD “scribble strips”
    • True preset spillover of delay and reverb tails for seamless preset changes
    • Firmware updates over USB
    • Compatible with Tone Master Pro Control desktop app for editing, sharing and downloading presets
    • Over 500 User Presets with access to thousands more from the Cloud using the Tone Master Pro Control App
    • Bluetooth wireless connection for streaming audio from a mobile device
    • Stereo 1/4″ Headphone output jack for silent practice
    • Compatible with the Mission Engineering SP1-TMP Expression Pedal for realtime control of parameters
    • Lightweight, under 9 lbs.
    • Patent Pending

    Спецификација

    Accessories

    Footswitch Connection Type
    1/4″


    Electronics

    Control Panel
    Navigation Control, Master Volume Control, 10 Footswitch/Encoders with LCD “Scribble Strips”

    Effects
    Over 100 Quality Amp and Effect Models

    Effects Loop
    4 Total

    Effects Loop Connection Type
    Mono Loops (1 & 2) 1/4″ Unbalanced, Mono Loops (3 & 4) 1/4″ TRS Balanced (Can Be Combined into Stereo Pair)

    Effects Loop Impedance
    10 kΩ

    Voltage
    120V

    Power Requirements
    40W

    Connectivity
    USB-C®

    Phantom Power
    +48 VDC (XLR Only)

    Digital Audio Bit Depth
    32 Bit

    Digital Audio Frequency Response
    20 Hz – 20 kHz (+0.1/-0.7 dB)

    Supported Sample Rates
    44.1 kHz Internal (Project Sync 44.1/48/88.2/96 kHz)

    Looper
    60-Second Stereo Looper

    Other Connections
    1/4″ Expression Pedal 1 and 2, Amp Control

    MIDI I/O
    Dual 5-Pin DIN (In/Out-Through-Merge)


    Miscellaneous

    Legal Notice
    WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov.

    Color
    Black


    Measurements

    Height
    3.8″ (96.4 mm)

    Width
    14.6″ (37.1 cm)

    Depth
    10.3″ (26.16 cm)

    Weight
    8.8 lbs (4 kg)


    Inputs

    Microphone Input Connection Type
    XLR Female (Combo), Balanced

    Microphone Preamp Maximum Input Level
    4.7V

    Microphone Preamp Input Impedance
    1.8 kΩ Balanced

    Instrument Inputs Maximum Level
    5.6V (2.8V with Input Pad Off)

    Instrument Inputs Impedance
    1 MΩ, 330 kΩ, 22 kΩ Configurable Unbalanced

    Instrument Input Connection Type
    1/4″

    Line Inputs Maximum Level
    7.8V Balanced, 4.5V Unbalanced

    Line Inputs Impedance
    1MΩ

    Line Input Connection Type
    1/4” TRS Female (Combo), Balanced

    Auxiliary Input Connection Type
    3.5 mm Stereo

    Auxiliary Input Impedance
    10 kΩ

    Auxiliary Input Max Input Level
    2.4V


    Outputs

    Headphone Outputs Maximum Output
    110mW x2

    Headphone Outputs Impedance Working Range
    33Ω x2 (16Ω x2 Minimum)

    Headphone Outputs Connection Type
    1/4” TRS Stereo, Unbalanced

    Line Outputs Connection Type
    1/4” TRS Female, Balanced (Stereo Pairs Output 1 and 2)

    Line Outputs Maximum Output Level
    Output 1 – 12V (Line) 3.9V (Instrument), Balanced; 6.1V (Line) 2.8V (Instrument), Unbalanced; Output 2 – 4.7V (Line) 2.8V (Instrument)

    Line Outputs Output Impedance
    Output 1 – 200Ω (Line) 290Ω Balanced, 400Ω Unbalanced (Instrument); Output 2 – 170Ω

    XLR Outputs Connection Type
    XLR Male, Balanced (Stereo Pair)
